Technical features 1st stage: Balanced diaphragm (seal chamber for mc9sc) 2 outlets hp 7/16 unf 4 outlets mp 3/8 unf Service pressure: 300 bar (4350 psi) din version, 232 bar (3365 psi) yoke version Calibration pressure: 10 bar Brass body electroless nickel plated High capacity conical fi lter electroless nickel plated Aisi 316 removable nozzle Hyper-balancing Anti-pressure drop pneumatic spring Setting spring: stainless steel with micropeening treatment Replaceable cylinder with anti-friction and anti-corrosion properties Elastomer protector Flow rate: 4500 l/min Yoke version weight: 590 gr Din version weight: 450 gr Technical features 2nd stage: Downstream system Adjustable venturi effect Patented antifriction lever Big purge button Anti-scratch surface Bayonet-type cap holder with security lock Removable exhaust tee without tools Weight without hose: 135 gr Combination performance: Average cracking effort 6 mbar Average breathing effort 1 j/l Jacketed hose extremely light and flexible weight: 153 gr Certification en250/2014 A>10° c
